Nylon Flour Mesh
Description
Description
100% nylon flour mesh--XXX series
| Introduction: With more than 30 years experiences in mesh, Shanghai SPRING can provide the high quality nylon flour mesh which is well used for flour milling machine. Shanghai SPRING Flour milling mesh include PAGG, PAXXX, PA MF, PETGG, PETXXX, PET Milling or PET XX. With good strength, anti-static and high flour extraction rate, SPRING nylon flour mesh is very popular to the milling factories from US, Europe, Southeast areas and South America areas. SPRING can provide you all the specifications and width under good quality and low price. All the Nylon flour mesh XXX series can meet FDA standards. Our products are available as ready-made articles and also as rolled goods for all types of sieving machines. We are able to supply millers with all products from one source for sieving, grading and dust removal, separator bags, connector sleeves, sieve cleaners and tensioning equipment. |
 |
Our Offer & Your Benefit:
- 100% nylon monofilament material PA6 or PA66
- Even mesh opening
- ISO9001, SGS
- FDA approval
- Width: 100CM-190CM, different width can be customized, the maximum width can reach 370CM
- Wide product range: 10GG-74GG; 6XXX-17XXX
- Long time service
- High reliability
- Low price with high quality
- Fast delivery
- High Throughout
- High yield
- Excellent after-sale service
- Samples can be provided before order
- Trial order or small order is available
Specification:
| Type | Mesh/inch | Mesh/CM | Wire Dia. (um) |
Mesh Opening (um) | Open Area (%) |
|---|---|---|---|---|---|
| PA-6XXX | 76.2 | 30 | 120 | 213 | 40.96 |
| PA-7XXX | 78.7 | 31 | 120 | 203 | 39.44 |
| PA-8XXX | 90.2 | 35.5 | 100 | 182 | 41.6 |
| PA-8.5XXX | 96.5 | 38 | 100 | 163 | 38.44 |
| PA-9XXX | 104.1 | 41 | 90 | 154 | 39.82 |
| PA-9.5XXX | 109.2 | 43 | 90 | 143 | 37.58 |
| PA-10XXX | 119.4 | 47 | 80 | 133 | 38.94 |
| PA-10.5XXX | 124.5 | 49 | 80 | 124 | 36.97 |
| PA-11XXX | 127 | 50 | 80 | 120 | 36 |
| PA-12XXX | 139.7 | 55 | 70 | 112 | 37.82 |
| PA-12.5XXX | 144.8 | 57 | 70 | 105 | 36.12 |
| PA-13XXX | 149.9 | 59 | 70 | 99 | 34.46 |
| PA-14XXX | 152.4 | 60 | 70 | 97 | 33.64 |
| PA-15XXX | 167.6 | 66 | 60 | 92 | 36.48 |
| PA-16XXX | 175.3 | 69 | 60 | 85 | 34.34 |
| PA-17XXX | 180.3 | 71 | 60 | 81 | 32.95 |
