Black mesh for window screen

Black polyester mesh for flyscreen

Item No.: 00096
110mesh to 200mesh Black polyester mesh for window screen
Description
Description

110mesh to 200mesh Black polyester mesh for window screen

A window screen also known as insect screen, bug screen, fly screen, flyscreen or flywire, is designed to cover the opening of a window. It is usually a mesh made of metal wire, fiberglass or polyester or nylon etc synthetic fiber and stretched in a frame of wood or metal. It serves to keep leaves, debris, insects, birds, and other animals from entering a building or a screened structure such as a porch, without blocking fresh air-flow.

For more information, please visit Wikipedia https://en.wikipedia.org/wiki/Window_screen.
Shanghai SPRING can provide you with different window screen, such as polyester mesh window screen, nylon mesh window screen, fiberglass window screen, aluminum window screen and stainless steel window screen.

For the polyester mesh window screen we have from 20mesh to 300mesh can be provided and both white and black color available. Different width and length can be customized. Nylon mesh window screen we can provide from 10mesh to 350mesh under request with different mesh opening. Fiberglass window screen specifications: 14*14mesh, 16*16mesh, 18*16mesh, 18*14mesh, 18*18mesh, with grey, black, light grey, green, white colors available, but popular colors are grey and black colors. Special colors or specifications can be make-to-order.

Aluminum window screen 20*22mesh, 16*18mesh, advantages for aluminum window screen: mesh opening is smaller than fiberglass, more wearable than fiberglass mesh, not prevent from lightness, fire-prevent.
See the source image

Specification details:

Type Weave Mesh/CM Mesh/inch Wire Dia. (um) Mesh Opening(um) Open Area (%) Thickness (um)
SP-20S PW 20 50 80 420 71 140
SP-20M PW 20 50 100 400 64 185
SP-20T PW 20 50 120 380 58 230
SP-20HT PW 20 50 150 350 49 290
SP-24S PW 24 60 80 337 65 150
SP-24M PW 24 60 100 317 58 190
SP-24T PW 24 60 120 297 51 235
SP-24HT PW 24 60 150 267 41 295
SP-29T PW 29 74 120 225 43 238
SP-32S PW 32 80 64 249 63 115
SP-32T PW 32 80 80 233 55 150
SP-32HT PW 32 80 100 213 46 180
SP-34T PW 34 86 100 194 44 185
SP-36T PW 36 90 100 178 41 190
SP-39S PW 39 99 55 201 62 90
SP-39T PW 39 99 80 176 47 150
SP-39HT PW 39 99 100 156 37 195
SP-43T PW 43 110 80 153 43 155
SP-47S PW 47 120 55 158 55 95
SP-47T PW 47 120 71 142 44 130
SP-53S PW 53 135 55 134 50 98
SP-53T PW 53 135 64 125 44 115
SP-53HT PW 53 135 71 118 39 133
SP-59S PW 59 150 55 114 46 100
SP-59T PW 59 150 64 105 39 118
SP-61T PW 61 155 64 100 37 119
SP-64T PW 64 163 64 92 35 120
SP-72S PW 72 183 48 91 43 75
SP-72T PW 72 183 55 84 37 105
SP-77T PW 77 195 55 75 33 108
SP-80T PW 80 203 48 77 38 77
SP-90T PW 90 230 48 63 32 80
SP-100T PW 100 254 40 60 36 65


Features & advantages:

  • 100% monofilament Polyester mesh yarn imported from Japan or Jintong in China
  • Warping machine imported from Germany
  • Imported Swiss Sulzer Ruti weaving machine
  • Special items can be customized
  • Best price, High quality & Excellent service
  • Maximum Width: 3730MM
  • ISO9001 Quality Management system
  • SGS certificate
  • Discs or special shape can be cut under request
  • Nylon or polyester or stainless steel material is available
Packages:
--- Rolled on paper tube or fold up
--- Label card
--- Put into plastic bag
--- Put into carton box
--- Sailcloth outside the carton
--- Special demand can be produced under request
